| รายละเอียดสินค้า |
Camera
| COMPONENT |
SPECIFICATION |
| Image Sensor |
Approx. 1/2.8 type CMOS image sensor |
| Scanning Area |
5.57 mm (H) × 3.13 mm (V) {7/32 inches (H) × 1/8 inches (V)} |
| Minimum Illumination |
Color :
0.13 lx (30IRE, F1.8, 1/30s, AGC:11)*
0.19 lx (50IRE, F1.8, 1/30s, AGC:11)
0.012 lx (50IRE, F1.8, 16/30s, AGC:11)*
BW :
0.10 lx (50IRE, F1.8, 1/30s, AGC:11)
0.006 lx (50IRE, F1.8, 16/30s, AGC:11)*
*Converted value |
| White Balance |
ATW1/ ATW2/ AWC |
| Shutter Speed |
[30 fps mode]
1/30 Fix to 1/10000 Fix
[25 fps mode]
1/25 Fix to 1/10000 Fix |
| Maximum Shutter |
[30 fps mode] Max. 1/4000 s to Max. 16/30 s
[25 fps mode] Max. 1/4000 s to Max. 16/25 s |
| Intelligent Auto |
On/Off |
| Super Dynamic |
On/Off (Range : 0 to 31) |
| Dynamic Range |
Max. 132 dB (Super Dynamic: On, Level: 31) |
| Adaptive Black Stretch |
The level can be set in the range of 0 to 255. |
| Back Light Compensation/High Light Compensation |
BLC (Back light compensation) / HLC (High light compensation) / Off (Range : 0 to 31)
*only when Super Dynamic/ Intelligent Auto: Off |
| Fog Compensation |
On/Off (Range : 0 to 8)
*only when Intelligent Auto / Auto contrast adjust: Off |
| Maximum Gain (AGC) |
The level can be set in the range of 0 to 11. |
| Color/BW (ICR) |
Off/ On/ Auto1/ Auto2/ Auto3(SCC) |
| IR LED Light |
- |
| Digital Noise Reduction |
The level can be set in the range of 0 to 255. |
| Video Motion Detection (VMD) |
On/ Off
4 areas available |
| Scene Change Detection (SCD) |
On/ Off
1 area available |
| Audio Detection |
On/ Off |
| AI Sound Classification |
Selectable from Gunshot, Yell, Vehicle horn, Glass break |
| Analytics |
AI Video Motion Detection, AI Privacy Guard, AI Face Detection, AI People Detection, AI Vehicle Detection, AI Occupancy Detection, AI Scene Change Detection
For details:
https://i-pro.com/products_and_solutions/en/surveillance/products/analytics-software
3rd party applications are also available.
https://i-pro.com/products_and_solutions/en/surveillance/solutions/edge-ai-platform/application-list |
| Max. Number of Applications |
3 |
| Privacy Zone |
On/Off
Up to 32 zones available
If privacy zone is enabled, frame rate will be limited to 15fps/12.5fps. |
| VIQS |
On/Off
Up to 8 zones available |
| Image Stabilizer |
On/Off
When image stabilization is set to On, the frame rate will be limited to 15fps/12.5fps. |
| Camera Title (OSD) |
On/Off
Up to 40 characters, Up to 2 lines (alphanumeric characters, marks) |
Lens
| COMPONENT |
SPECIFICATION |
| Optical Zoom |
30x (Motorized zoom / Motorized focus) |
| Extra Zoom |
- |
| Digital (electronic) Zoom |
30x - 480x |
| Focal Length |
4.5 mm – 135 mm {3/16 inches – 5-5/16 inches} |
| Angular Field of View |
[16:9 mode]
Horizontal: 2.5° (TELE) – 62° (WIDE)
Vertical: 1.4° (TELE) – 37° (WIDE) |
| Adjusting Angle |
(PAN) angle : 0° - +350°
(TILT) angle : -25° - +90°
(YAW) angle : ±0° |
| Maximum Aperture Ratio |
1:1.8 (WIDE) – 1:4.7 (TELE) |
| Focus Range |
3.0 m {118-1/8 inches} – ∞ |
| Aperture Range |
F1.8 – Close |
DORI
| COMPONENT |
SPECIFICATION |
| Detect (25ppm / 8ppf) |
3050.4 m {10007.9 ft} (TELE) 110.8 m {363.4 ft} (WIDE) |
| Observe (62.5ppm / 19ppf) |
1220.2 m {4003.2 ft} (TELE) 44.3 m {145.4 ft} (WIDE) |
| Recognize (125ppm / 38ppf) |
610.1 m {2001.6 ft} (TELE) 22.2 m {72.7 ft} (WIDE) |
| Identify (250ppm / 76ppf) |
305.0 m {1000.8 ft} (TELE) 11.1 m {36.3 ft} (WIDE) |
System on Chip
| COMPONENT |
SPECIFICATION |
| System on Chip (SoC) |
Ambarella CV22 |
Pan/Tilt
| COMPONENT |
SPECIFICATION |
| Panning Range |
0° to +350° |
| Panning Speed |
Manual: Approx.0.065 °/s – 150 °/s
Preset: Up to approx. 500 °/s |
| Tilting Range |
Operational range: -25°– +90° (level – downward) |
| Tilting Speed |
Manual: Approx. .0.065 °/s – 150°/s
Preset: Up to approx. 350 °/s |
| Preset Positions |
256 |
| Auto Mode |
Auto track, Auto pan, Preset sequence, Patrol |
| Self Return |
10 s, 20 s, 30 s, 1 min, 2 min, 3 min, 5 min, 10 min, 20 min, 30 min, 60 min |
Browser GUI
| COMPONENT |
SPECIFICATION |
| GUI / Setup Menu Language |
English, Italian, French, German, Spanish, Portuguese,
Russian, Chinese, Japanese |
| Browser *1 |
Microsoft Edge
Firefox
Google Chrome |
Network
| COMPONENT |
SPECIFICATION |
| Network IF |
10BASE-T/100BASE-TX, RJ45 connector |
| Resolution |
[16:9 mode (30 fps mode)] [16:9 mode (25 fps mode)]
3328x1872/2560x1440/1920x1080/1280x720/640x360/320x180
[4:3 mode]
- |
| H.265/H.264 Transmission Mode/Type |
[Transmission Mode]
Constant bit rate/ VBR/ Frame rate/ Best effort
[Transmission Type]
Unicast port (AUTO)/ Unicast port (MANUAL)/ Multicast |
| No. of Stream |
4 |
| JPEG (MJPEG) Image Quality |
10 steps: 0(SUPER FINE) - 9(LOW) |
| Smart Coding |
[GOP(Group of pictures) control]
Off/ Low (Variable GOP 1s-8s)/Mid (Variable GOP 4s-16s)/ Advanced (Fixed GOP 60 seconds with 1 second Key frame)/ Frame rate control (Variable GOP 4s-16s with frame rate control)
*Advanced and Frame rate control are only available with H.265.
[Smart VIQS]
On (High)/ On (Low)/ Off
[Smart P-picture control]
On/Off |
| Audio Compression Method *2 |
G.726 (ADPCM): 16 kbps/ 32 kbps
G.711: 64 kbps
AAC-LC : 64 kbps/ 96 kbps/ 128 kbps |
| No. of Simultaneous Users |
Up to 14 users (Depends on network conditions) |
| Secure |
FIPS 140-2 level 3 (NXP® EdgeLock® SE050F),
Device Certificate GlobalSign® pre-installed, HTTPS,
User authentication, digest authentication, Host authentication,
IEEE802.1X, System log, Image transmission log, brute-force protection,
Alteration Detection, Signed Firmware |
| SDXC/SDHC/SD Memory Card (Option) |
microSDXC memory card: 64 GB, 128 GB, 256 GB, 512 GB
microSDHC memory card: 4 GB, 8 GB, 16 GB, 32 GB
microSD memory card: 2 GB |
| Mobile Terminal Compatibility |
iPad / iPhone (iOS 8.0 or later),
Android™ terminals |
| ONVIF®Profile |
G / S / T / M |
Input/Output
| COMPONENT |
SPECIFICATION |
| Audio Input |
ø3.5 mm stereo mini jack |
| Audio Output |
ø3.5 mm stereo mini jack (Audio output is monaural.)
Output impedance: Approx. 600 Ω (unbalanced)
Output level: -20 dBV |
| External I/O Terminals |
ALARM IN1
(Alarm input 1/ Black & white input/ Auto time adjustment input) (x1)
ALARM IN2 (Alarm input 2/ ALARM OUT) (x1)
ALARM IN3 (Alarm input 3/ AUX OUT) (x1) |
| Monitor Output |
- |
General
| COMPONENT |
SPECIFICATION |
| Safety |
UL (UL62368-1), c-UL (CSA C22.2 No.62368-1), CE, IEC62368-1 |
| EMC |
FCC (Part15 ClassA), ICES-003 ClassA, EN55032 ClassA, EN55035 |
| Power Source/Power Consumption |
[Power Source]
DC12V *3 PoE+ (IEEE802.3at compliant)
[Power Consumption]
DC12 V : 1.25 A / Approx. 15.0 W
PoE+ DC 54 V : 310 mA / Approx. 16.7 W (Class 4 device) |
| Ambient Operating Temperature |
-10 °C to +50 °C {14 °F to +122 °F}
(Power On range: 0 °C to +50 °C {32 °F to +122 °F}) |
| Ambient Operating Humidity |
10 % to 90 % (no condensation) |
| Dimensions |
ø185 mm × 214 mm (H) {ø7-9/32 inches × 8-7/16 inches (H)} |
| Mass (approx.) |
Approx. 1.8 kg {3.97 lbs}
(Including camera mount bracket: approx.100 g {0.22 lbs}, decorative cover: approx. 150 g {0.33 lbs}) |
| Finish |
Main body: Aluminium die cast /ABS resin, i-PRO white
Lens cover: ABS resin, Black |
| Easy Kitting |
Yes |
|
