| รายละเอียดสินค้า |
Camera
| COMPONENT |
SPECIFICATION |
| Image Sensor |
Approx. 1/2 type 12MP CMOS image sensor |
| Minimum Illumination |
Color :
0.2 lx (30IRE, F1.9, 1/30s, AGC:11)*
0.3 lx (50IRE, F1.9, 1/30s, AGC:11)
0.02 lx (50IRE, F1.9, 16/30s, AGC:11)*
BW :
0 lx (50IRE, F1.9, 1/30s, AGC:11, IR LED: On)
0.04 lx (50IRE, F1.9, 1/30s, AGC:11)
0.003 lx (50IRE, F1.9, 16/30s, AGC:11)*
*Converted value |
| Intelligent Auto |
On / Off |
| Maximum Shutter |
max. 16/30s to Max. 1/10000s |
| Super Dynamic |
On / Off,
The level can be set in the range of 0 to 31. |
| Dynamic Range |
Max.84 dB
(Wide Dynamic Range : On, level : 31) |
| Image Settings |
Gain (AGC), White balance |
| Image Compensation |
Adaptive black stretch, Back light compensation (BLC), Fog compensation, High light compensation (HLC), Digital noise reduction |
| Color/BW (ICR) |
Off / On (IR Light Off) / On (IR Light On) / Auto1 (IR Light Off) / Auto2 (IR Light On) / Auto3 (SCC) |
| IR LED Light |
High* / Middle / Low / Off
*Maximum irradiation distance : 14 m{Approx. 45 ft}(30IRE), 10 m {Approx. 33 ft} (Mounting height : Approx. 3 m, Peripheral intensity control : On) |
| Video Motion Detection (VMD) |
On / Off,
4 areas available |
| Scene Change Detection (SCD) |
On / Off,
1 areas available |
| Audio Detection |
On / Off |
| AI Sound Classification |
Gunshot, Yell, Vehicle horn, Glass break |
| AI Analytics |
AI-VMD/AI People Counting for 360-degree fisheye camera, AI Privacy Guard for 360-degree fisheye camera, AI Non mask Detection (prior to V2.70), AI Scene Change Detection
For details :
https://i-pro.com/products_and_solutions/en/surveillance/products/analytics-software
3rd party applications are also available.
https://i-pro.com/products_and_solutions/en/surveillance/solutions/edge-ai-platform/application-list |
| Privacy Zone |
On / Off,
Up to 8 zones available |
| Camera Title (OSD) |
On / Off, Up to 20 characters (alphanumeric characters, marks) |
| Fixing angle adjustment |
-5°, 0°, +5° |
Lens
| COMPONENT |
SPECIFICATION |
| Zoom Ratio |
1x |
| Digital (Electronic) Zoom |
Choose from 3 levels of x1, x2, x4 |
| Focal Length |
1.4 mm {1/16 inches} |
| Maximum Aperture Ratio |
1:1.9 |
| Focus Range |
0.5 m {19-11/16 inches} - ∞ |
| Angular Field of View |
Horizontal : 183°
Vertical : 183° |
DORI
| COMPONENT |
SPECIFICATION |
| Distance to the object in the center of the image |
Detect (25 ppm / 8 ppf) : 29.9m / 98.2ft
Observe (62.5 ppm / 19 ppf) : 12.0m / 39.3ft
Recognize (125 ppm / 38 ppf) : 6.0m / 19.6ft
Identify (250 ppm / 76 ppf) : 3.0m / 9.8ft |
| Coverage radius when mounted at a height of 3 m (10 ft) |
Detect (25 ppm / 8 ppf) : 56.1m /184.2ft
Observe (62.5 ppm / 19 ppf) : 20.6m / 67.6ft
Recognize (125 ppm / 38 ppf) : 8.4m / 27.6ft
Identify (250 ppm / 76 ppf) : 0.3m / 0.9ft |
System on Chip (SoC)
| COMPONENT |
SPECIFICATION |
| System on Chip (SoC) |
Ambarella CV22 |
Browser GUI
| COMPONENT |
SPECIFICATION |
| Camera Control |
Brightness, AUX On / Off |
| Audio |
Mic (Line) Input :
On / Off Volume adjustment : Low / Middle / High
Audio Output :
On / Off Volume adjustment : Low / Middle / High |
| GUI / Setup Menu Language |
English, Italian, French, German, Spanish, Portuguese, Russian,
Chinese, Japanese |
Network
| COMPONENT |
SPECIFICATION |
| Network IF |
10Base-T / 100Base-TX, M12 connector |
| Resolution <Ceiling> <Wall> |
•Fisheye mode (max. 30 fps/25 fps)
2992×2992 / 2192×2192 / 1280×1280 / 640×640 / 320×320
•Quad PTZ mode (max. 15 fps/12.5 fps), Single PTZ mode (max. 15 fps/12.5 fps)
2560×1920 / 2048×1536 / 1600×1200 / 1280×960 / 800×600 / VGA / QVGA |
| Resolution <Ceiling> |
•Double Panorama mode (max. 15 fps/12.5 fps)
2560×1440 / 1920×1080 / 1280×720 / 640×360 / 320×180
•Fisheye + Double Panorama mode (max. 15 fps/12.5 fps)
(Fisheye) 2992×2992 / 2192×2192 / 1280×1280 / 640×640 / 320×320
(Double Panorama) 1280×720 / 640×360 / 320×180
•Fisheye + Quad PTZ mode (max. 15 fps/12.5 fps)
(Fisheye) 2992×2992 / 2192×2192 / 1280×1280 / 640×640 / 320×320
(Quad PTZ) 1280×960 / 800×600 / VGA / QVGA
•Quad streams mode
(Single PTZ (Quad streams)) 1280×960 / 800×600 / VGA / QVGA (max. 15 fps/12.5 fps)
(Quad PTZ) 2560×1920 / 2048×1536 / 1600×1200 / 1280×960 / 800×600 / VGA / QVGA (max. 5 fps) |
| Resolution <Wall> |
•Panorama mode (max. 15 fps/12.5 fps)
2560×1440 / 1920×1080 / 1280×720 / 640×360 / 320×180
•Fisheye + Panorama mode (max. 15 fps/12.5 fps)
(Fisheye) 2992×2992 / 2192×2192 / 1280×1280 / 640×640 / 320×320
(Panorama) 1280×720 / 640×360 / 320×180 |
| H.265/H.264 |
[Transmission Mode]
Constant bit rate / VBR / Frame rate / Best effort
[Transmission Type]
Unicast port (AUTO)/ Unicast port (MANUAL)/ Multicast |
| JPEG |
[Image Quality]
10 steps |
| Smart Coding |
GOP (Group of pictures) control :
On (Frame rate control)* / On (Advanced)* / On (Mid) / On (Low) / Off
*On (Frame rate control) and On (Advanced) are only available with H.265.
Auto VIQS : On / Off |
| Audio Compression |
G.726 (ADPCM) : 16 kbps / 32 kbps
G.711 : 64 kbps
AAC-LC : 64 kbps / 96 kbps / 128 kbps |
| Supported Protocol |
IPv6 : TCP/IP, UDP/IP, HTTP, HTTPS, SSL/TLS, SMTP, DNS, NTP, SNMPv1/v2/v3, DHCPv6,RTP, MLD, ICMP, ARP, IEEE 802.1X,DiffServ, FTP, SFTP, MQTT, LLDP
IPv4 : TCP/IP, UDP/IP, HTTP, HTTPS, SSL/TLS, RTSP, RTP, RTP/RTCP, SMTP, DHCP, DNS, DDNS, NTP, SNMPv1/v2/v3, UPnP, IGMP, ICMP, ARP, IEEE 802.1X, DiffServ, SRTP, FTP, SFTP, MQTT, LLDP |
| Maximum concurrent accessnumber |
Up to 14 users (Depends on network conditions) |
| Secure |
FIPS 140-2 level 3 (NXP® EdgeLock® SE050F), Device Certificate GlobalSign® pre-installed,
HTTPS, User authentication, Digest authentication, Host authentication,
IEEE802.1X, System log, Image transmission log, Brute-force protection, Alteration detection, Signed Firmware |
| SDXC/SDHC/SD Memory Card (Option) |
H.265 / H.264 recording :
Manual REC / Alarm REC (Pre/Post) / Schedule REC / JPEG recording : Manual REC / Alarm REC (Pre/Post)
Compatible SDXC/SDHC/SD card :
2 GB, 4 GB*, 8 GB*, 16 GB*, 32 GB*, 64 GB**, 128 GB**, 256 GB**, 512GB**model
*SDHC card, ** SDXC card (except miniSD card and microSD card) |
| Mobile Terminal Compatibility |
iPad / iPhone
AndroidTM terminals |
| ONVIF Profile |
G / M / S / T |
Alarm
| COMPONENT |
SPECIFICATION |
| Alarm Source |
3 terminals input, VMD, Command alarm |
| Alarm Actions |
SDXC/SDHC/SD memory recording, E-mail notification, HTTP alarm notification,
Indication on browser, TCP alarm notification output |
Input/Output
| COMPONENT |
SPECIFICATION |
| Audio Input |
[For microphone]
ø3.5 mm stereo mini jack, Recommended applicable microphone : Plug-in power type
(Sensitivity of microphone : –48 dB ±3 dB (0 dB=1 V / Pa,1 kHz))
Input impedance : Approx. 2 kΩ (unbalanced) Supply voltage : 2.5 V ±0.5 V
[For line]
Input level : Approx. –10 dBV |
| Audio Output |
ø3.5 mm stereo mini jack (monaural output)
Output impedance : Approx. 600 Ω (unbalanced)
Output level : –20 dBV |
| External I/O Terminals |
ALARM IN1 (Alarm input 1/ Black & white input/ Auto time adjustment input) (x1)
ALARM IN2 (Alarm input 2/ ALARM OUT) (x1)
ALARM IN3 (Alarm input 3/ AUX OUT) (x1) |
| Monitor Output |
Yes (for adjustment)
Φ3.5mm stereo mini jack, NTSC or PAL signal can be output from camera |
General
| COMPONENT |
SPECIFICATION |
| Safety |
UL (UL62368-1), c-UL (CSA C22.2 No.62368-1),
CE, IEC62368-1 |
| EMC |
FCC (Part15 ClassA), ICES003 ClassA, EN55032 ClassB, EN55035
ECE-R10, EN50498 compliant, EN50121 |
| Power Source and Power Consumption |
DC power supply : DC 12 V 1.1 A/Approx. 13.2 W , PoE (IEEE802.3af compliant, Alternative A)
Device : DC 48 V 270 mA/Approx. 12.95 W (Class 0 device) |
| Ambient Operating Temperature |
IR LED : On -40 °C to +50 °C (-40 °F to 122 °F) / Off -40 °C to +60 °C (-40 °F to 140 °F) |
| Ambient Operating Humidity |
10 to 100 % (no condensation) |
| Anti-Condensation System |
Rosahl element |
| Water and Dust Resistance |
IP66(IEC60529), Type 4X(UL50), NEMA 4X compliant |
| Shock Resistance |
50J (IEC 60068-2-75 compliant),
IK10 (IEC 62262) |
| Wind Resistance |
Up to 40 m/s {approx. 89 mph} |
| Railway Application |
EN45545 compliant,
EN50155-TX |
| Dimensions |
When using the attachment plate only :
ø154 mm × 60.3 mm (H) {ø6-1/16 inches × 2-3/8 inches (H)}
Dome radius 35 mm {1-3/8 inches} |
| Mass (Approx.) |
When using the attachment plate only :
Approx. 880 g {1.94 lbs} |
| Finish |
Main body : Aluminum die cast, i-PRO white
Outer fixing screws : Stainless steel (Corrosion-resistant treatment)
Dome section : Polycarbonate resin, Clear |
|
