| รายละเอียดสินค้า |
Camera
| COMPONENT |
SPECIFICATION |
| Image Sensor |
1/2.8 type CMOS image sensor |
| Minimum Illumination |
Color : 0.07 lx, BW : 0.04 lx
(50IRE, F1.3, Maximum shutter : Off (1/30s), AGC : 11)
BW : 0 lx
(50IRE, F1.3, Maximum shutter : Off (1/30 s), AGC : 11, when the IR LED is lit)
Color : 0.0044 lx, BW : 0.003 lx
(50IRE, F1.3, Maximum shutter : max. 16/30s, AGC : 11) |
| White Balance |
ATW1/ ATW2/ AWC |
| Shutter Speed |
[30fps mode] 1/30 Fix to 1/10000 Fix, [25fps mode] 1/25 Fix to 1/10000 Fix |
| Intelligent Auto |
On / Off |
| Super Dynamic |
On / Off, The level can be set in the range of 0 to 31. |
| Dynamic Range |
Max. 132 dB (Super Dynamic : On, Level : 30 or more, 15fps) |
| Adaptive Black Stretch |
The level can be set in the range of 0 to 255. |
| Back Light Compensation/High Light Compensation |
BLC (Back light compensation) / HLC (High light compensation) / Off
The level can be set in the range of 0 to 31.
(only when Super dynamic / Intelligent Auto : Off) |
| Fog Compensation |
On / Off, The level can be set in the range of 0 to 8
(only when Intelligent auto / auto contrast adjust : Off) |
| Maximum Gain (AGC) |
The level can be set in the range of 0 to 11. |
| Color/BW (ICR) |
Off / On (IR Light Off) / On (IR Light On) / Auto1 (IR Light Off) / Auto2 (IR Light On) / Auto3 (SCC) |
| IR LED Light |
High / Middle / Low / Off, Maximum irradiation distance : 40 m {Approx. 131 ft} |
| Digital Noise Reduction |
The level can be set in the range of 0 to 255. |
| Video Motion Detection (VMD) |
On / Off, 4 areas available |
| Scene Change Detection (SCD) |
On / Off, 1 areas available |
| Intelligent VMD (i-VMD) |
Type 7 *Bundled License |
| Privacy Zone |
On / Off, Up to 8 zones available |
| Image Rotation |
0 ° (Off) / 90 °/ 180 ° (Upside-down)/ 270 ° |
| Camera Title (OSD) |
On / Off, Up to 20 characters (alphanumeric characters, marks) |
Lens
| COMPONENT |
SPECIFICATION |
| Optical zoom |
3.1x (Motorized zoom / Motorized focus) |
| Extra zoom |
3.1x - 9.3x (when resolution is 640x360) |
| Digital (electronic) zoom |
Choose from 3 levels of x1, x2, x4 |
| Focal length |
2.9 mm - 9 mm {1/8 inches – 11/32 inches} |
| Maximum Aperture Ratio |
1 : 1.3 (WIDE) – 1 : 2.5 (TELE) |
| Focus range |
0.3 m {11-13/16 inches} – ∞ |
| Angular Field of View |
[16 : 9 mode] Horizontal : 33° (TELE) – 103° (WIDE), Vertical : 19° (TELE) – 55° (WIDE)
[ 4 : 3 mode] Horizontal : 33° (TELE) – 103° (WIDE), Vertical : 25° (TELE) – 75° (WIDE) |
DORI
| COMPONENT |
SPECIFICATION |
| Detect (25ppm / 8ppf) |
Wide: 48.87 m / 160.34 ft, Tele: 207.42 m / 680.51 ft |
| Observe (62.5ppm / 19ppf) |
Wide: 19.55 m / 64.14 ft, Tele: 82.97 m / 272.20 ft |
| Recognize (125ppm / 38ppf) |
Wide: 9.77 m / 32.07 ft, Tele: 41.48 m / 136.10 ft |
| Identify (250ppm / 76ppf) |
Wide: 4.89 m / 16.03 ft, Tele: 20.74 m / 68.05 ft |
Adjusting Angle
| COMPONENT |
SPECIFICATION |
| Adjusting Angle |
Horizontal (PAN) angle : ±180°, Vertical (TILT) angle : -30 to +85°,
Azimuth (YAW) angle : ±100° |
Browser GUI
| COMPONENT |
SPECIFICATION |
| Camera Control |
Brightness, AUX On / Off |
| Audio |
Mic (Line) Input : On / Off Volume adjustment : Low / Middle / High
Audio Output : On / Off Volume adjustment : Low / Middle / High |
| GUI / Setup Menu Language |
English, Italian, French, German, Spanish, Portuguese, Russian, Chinese, Japanese |
| Browser |
Microsoft Edge, Firefox, Google Chrome |
Network
| COMPONENT |
SPECIFICATION |
| Network IF |
10Base-T / 100Base-TX, RJ45 connector |
| Resolution H.265/ H.264/ JPEG (MJPEG) |
[16 : 9 mode] 3072 x 1728*7 / 2560 x 1440 / 1920 x 1080 / 1280 x 720 / 640 x 360 / 320 x 180
[ 4 : 3 mode] 3072 x 2304*7 / 2560 x 1920 / 1280 x 960 / 800 x 600 / VGA / 400 x 300 / QVGA |
| H.265/H.264 |
[Transmission Mode]
Constant bit rate / VBR / Frame rate / Best effort
[Transmission Type]
Unicast port (AUTO) / Unicast port (MANUAL) / Multicast |
| JPEG |
[Image Quality] 10 steps |
| Smart Coding |
GOP (Group of pictures) control :
On (Frame rate control)* / On (Advanced)* / On (Mid) / On (Low) / Off
*On (Frame rate control) and On (Advanced) are only available with H.265.
Auto VIQS : On / Off |
| Audio Compression |
G.726 (ADPCM) : 16 kbps / 32 kbps G.711 : 64 kbps, AAC-LC : 64 kbps / 96 kbps / 128 kbps |
| Audio Transmission Mode |
Off / Mic (Line) input / Audio output / Interactive (Half duplex) / Interactive (Full duplex) |
| Supported Protocol |
IPv6 : TCP/IP, UDP/IP, HTTP, HTTPS, SMTP, DNS, NTP, SNMP, DHCPv6, RTP, MLD,
ICMP, ARP, IEEE 802.1X, DiffServ, SSL/TLS, SRTP, SFTP, MQTT, LLDP
IPv4 : TCP/IP, UDP/IP, HTTP, HTTPS, RTSP, RTP, RTP/RTCP,
SMTP, DHCP, DNS, DDNS, NTP, SNMP, UPnP, IGMP, ICMP,
ARP, IEEE 802.1X, DiffServ, SSL/TLS, SRTP, SFTP, MQTT, LLDP |
| No. of Simultaneous Users |
Up to 14 users (Depends on network conditions) |
| Secure |
FIPS 140-2 level3 |
| SDXC/SDHC/SD Memory Card |
H.265 / H.264 recording :
Manual REC / Alarm REC (Pre/Post) / Schedule REC / Backup upon network failure
JPEG recording : Manual REC / Alarm REC (Pre/Post)
Compatible SDXC/SDHC/SD Memory Card :
Panasonic 2 GB, 4 GB*, 8 GB*, 16 GB*, 32 GB*, 64 GB**, 128 GB**, 256 GB**model
*SDHC card, ** SDXC card (except miniSD card and microSD card) |
| Mobile Terminal Compatibility |
iPad, iPhone, AndroidTM terminals |
| ONVIF® Profile |
G / S / T |
Alarm
| COMPONENT |
SPECIFICATION |
| Alarm Source |
3 terminals input, VMD alarm, SCD alarm, Command alarm |
| Alarm Actions |
SDXC/SDHC/SD memory recording, E-mail notification, HTTP alarm notification,
Indication on browser, TCP alarm notification output |
Input/Output
| COMPONENT |
SPECIFICATION |
| Audio input |
ø3.5 mm stereo mini jack
For microphone input : Recommended applicable microphone : Plug-in power type
(Sensitivity of microphone : -48 dB±3 dB (0 dB=1 V/Pa, 1 kHz))
Input impedance : Approx. 2 kΩ (unbalanced)
Supply voltage : 2.5 V ±0.5 V
For line input : Input level: Approx. –10 dBV |
| Audio Output |
ø3.5 mm stereo mini jack (Audio output is monaural.)
Output impedance : Approx. 600 Ω (unbalanced)
Output level : –20 dBV |
| External I/O Terminals |
ALARM IN 1(Alarm input 1/ Black & white input/ Auto time adjustment input) (x1)
ALARM IN 2 (Alarm input 2/ ALARM OUT) (x1) , ALARM IN 3 (Alarm input 3/ AUX OUT) (x1) |
| Monitor Output |
Yes (for adjustment)
Φ3.5mm stereo mini jack, NTSC or PAL signal can be output from camera |
General
| COMPONENT |
SPECIFICATION |
| Safety |
UL (UL60950-1), c-UL (CSA C22.2 No.60950-1), CE, IEC60950-1 |
| EMC |
FCC (Part15 ClassA), ICES003 ClassA, EN55032 ClassB, EN55024 |
| Power Source and Power Consumption |
DC power supply : DC 12 V 980 mA/Approx. 11.8 W
PoE (IEEE802.3af compliant) Device : DC48 V 260 mA/ Approx. 12.5 W (Class 0 device) |
| Ambient Operating Temperature |
-40 °C to +60 °C (-40 °F to +140 °F)
(Power On range : –30 °C to +60 °C {–22 °F to +140 °F}) |
| Ambient Operating Humidity |
10 to 100 % (no condensation) |
| Anti-Condensation System |
Temish element+Fan/Heater |
| Water and Dust Resistance |
IP66 (IEC60529), Type 4X(UL50E), NEMA 4X compliant |
| Shock Resistance |
50J (IEC 60068-2-75 compliant), IK10 (IEC 62262) |
| Wind Resistance |
Up to 40 m/s {approx. 89 mph} |
| Dimensions |
When using base bracket : ø164 mm × 139 mm (H) {ø6-15/32 inches × 5-15/32 inches (H)}
Dome radius 42 mm {1-21/32 inches}
When using attachment plate only : ø154 mm × 103 mm (H) {ø6-1/16 inches × 4-1/16 inches (H)}
Dome radius 42 mm {1-21/32 inches} |
| Mass |
When using base bracket : Approx. 1.6 kg {3.53 lbs}
When using attachment plate only : Approx. 1.2 kg {2.65 lbs} |
| Finish |
Main body : Aluminum die cast, i-PRO white
Outer fixing screws : Stainless steel (Corrosion-resistant treatment)
Dome cover : Polycarbonate resin, Clear |
|
