| รายละเอียดสินค้า |
Camera
| COMPONENT |
SPECIFICATION |
| Image Sensor |
Approx. 1/2.8 type CMOS image sensor |
| Scanning Area |
5.57 mm (H) × 3.13 mm (V) {7/32 inches (H) × 1/8 inches (V)} |
| Minimum Illumination |
Color : 0.13 lx (30IRE, F1.8, 1/30s, AGC:11)
Color : 0.19 lx (50IRE, F1.8, 1/30s, AGC:11)
BW : 0.10 lx (50IRE, F1.8, 1/30s, AGC:11) |
| White Balance |
ATW1/ ATW2/ AWC |
| Shutter Speed |
[30 fps mode] 1/30 Fix to 1/10000 Fix
[25 fps mode] 1/25 Fix to 1/10000 Fix |
| Maximum Shutter |
[30 fps mode] Max. 1/4000 s to Max. 16/30 s
[25 fps mode] Max. 1/4000 s to Max. 16/25 s |
| Intelligent Auto |
On/Off |
| Super Dynamic |
On/Off (Range : 0 to 31) |
| Dynamic Range |
Max. 132 dB (Super Dynamic: On, Level: 31) |
| Adaptive Black Stretch |
The level can be set in the range of 0 to 255. |
| Back Light Compensation/High Light Compensation |
BLC (Back light compensation) / HLC (High light compensation) / Off (Range : 0 to 31)
*only when Super Dynamic/ Intelligent Auto: Off |
| Fog Compensation |
On/Off (Range : 0 to 8)
*only when Intelligent Auto / Auto contrast adjust: Off |
| Maximum Gain (AGC) |
The level can be set in the range of 0 to 11. |
| Color/BW (ICR) |
Off(White Light Off)/ Off(White Light On)/ On(White Light Off)/ On(White Light On)/ Auto1(White Light Off)/ Auto1(White Light On)/ Auto2(IR Light)/ Auto3(SCC) |
| White LED Light |
[AC100~240V, PoE++ Type4 Class 8]
Maximum irradiation distance:
160 m {Approx. 1148 ft} (30IRE)*
120 m {Approx. 820 ft} (50IRE)
* Converted value
[PoE++ Type3 Class 6]
- |
| Digital Noise Reduction |
The level can be set in the range of 0 to 255. |
| Video Motion Detection (VMD) |
On/ Off
4 areas available |
| Scene Change Detection (SCD) |
On/ Off
1 area available |
| Audio Detection |
On/ Off |
| AI Sound Classification |
Selectable from Gunshot, Yell, Vehicle horn, Glass break |
| Analytics |
AI Video Motion Detection, AI Face Detection, AI Privacy Guard, AI People Detection, AI Vehicle Detection, AI Occupancy Detection
For details:
https://i-pro.com/products_and_solutions/en/surveillance/products/analytics-software
3rd party applications are also available.
https://i-pro.com/products_and_solutions/en/surveillance/solutions/edge-ai-platform/application-list |
| Max. Number of Applications |
3 |
| Privacy Zone |
On/Off
Up to 32 zones available |
| VIQS |
On/Off
Up to 8 zones available |
| Image Stabilizer |
On/Off (Built-in gyro sensor)
Available only in the 30/25 fps mode (Built-in gyro sensor) |
| Camera Title (OSD) |
On/Off
Up to 40 characters, Up to 2 lines (alphanumeric characters, marks) |
Lens
| COMPONENT |
SPECIFICATION |
| Optical Zoom |
30x |
| Extra Zoom |
- |
| Digital (electronic) Zoom |
|
| Focal Length |
4.5 mm – 135 mm {3/16 inches – 5-5/16 inches} |
| Angular Field of View |
[16:9 mode]
Horizontal: 2.5° (TELE) – 62° (WIDE)
Vertical: 1.4° (TELE) – 37° (WIDE) |
| Adjusting Angle |
(PAN) angle : 360° turning
(TILT) angle : -90° - +90°
(YAW) angle : ±0° |
| Maximum Aperture Ratio |
1:1.8 (WIDE) – 1:4.7 (TELE) |
| Focus Range |
3.0 m {118-1/8 inches} – ∞ |
| Aperture Range |
F1.8 – Close |
DORI
| COMPONENT |
SPECIFICATION |
| Detect (25ppm / 8ppf) |
3519.7 m {11547.6 ft} (TELE) 127.8 m {419.3 ft} (WIDE) |
| Observe (62.5ppm / 19ppf) |
1407.9 m {4619.0 ft} (TELE) 51.1 m {167.7 ft} (WIDE) |
| Recognize (125ppm / 38ppf) |
703.9 m {2309.5 ft} (TELE) 25.6 m {83.9 ft} (WIDE) |
| Identify (250ppm / 76ppf) |
352.0 m {1154.8 ft} (TELE) 12.8 m {41.9 ft} (WIDE) |
System on Chip
| COMPONENT |
SPECIFICATION |
| System on Chip (SoC) |
Ambarella CV22 |
Pan/Tilt
| COMPONENT |
SPECIFICATION |
| Panning Range |
360° Endless panning |
| Panning Speed |
Manual : Approx. 0.065 °/s – 100 °/s *
*Except when frozen
Preset : Up to approx. 200 °/s *
*Except when leaning forward, frozen, or in strong winds |
| Tilting Range |
Operating range:
- Upright: -45° to +90° (level - upward)
- Leaning forward: -90° to +90° (downward - level - upward)
- Hanging: -30° to +90° (level - downward) |
| Tilting Speed |
Manual: Approx. 0.065 °/s – 100 °/s *
*Except when frozen
Preset: Up to approx. 200°/s
*Except when leaning forward, frozen, or in strong winds |
| Preset Positions |
256 |
| Auto Mode |
Auto track, Auto pan, Preset sequence, Patrol |
| Self Return |
10 s, 20 s, 30 s, 1 min, 2 min, 3 min, 5 min, 10 min, 20 min, 30 min, 60 min |
Browser GUI
| COMPONENT |
SPECIFICATION |
| GUI / Setup Menu Language |
English, Italian, French, German, Spanish, Portuguese,
Russian, Chinese, Japanese |
| Browser *1 |
Microsoft Edge
Firefox
Google Chrome |
Network
| COMPONENT |
SPECIFICATION |
| Network IF |
10BASE-T/100BASE-TX, RJ45 connector |
| Resolution |
[16:9 mode(30 fps mode)][16:9 mode(25 fps mode)]
3840×2160/ 2560×1440/ 1920×1080/ 1280×720/ 640×360/ 320×180
[4:3 mode]
- |
| H.265/H.264 Transmission Mode/Type |
[Transmission Mode]
Constant bit rate/ VBR/ Frame rate/ Best effort
[Transmission Type]
Unicast port (AUTO)/ Unicast port (MANUAL)/ Multicast |
| No. of Stream |
4 |
| JPEG (MJPEG) Image Quality |
10 steps: 0(SUPER FINE) - 9(LOW) |
| Smart Coding |
[GOP(Group of pictures) control]
Off/ Low (Variable GOP 1s-8s)/Mid (Variable GOP 4s-16s)/ Advanced (Fixed GOP 60 seconds with 1 second Key frame)/ Frame rate control (Variable GOP 4s-16s with frame rate control)
*Advanced and Frame rate control are only available with H.265.
[Smart VIQS]
On (High)/ On (Low)/ Off
[Smart P-picture control]
On/Off |
| Audio Compression Method *2 |
G.726 (ADPCM): 16 kbps/ 32 kbps
G.711: 64 kbps
AAC-LC : 64 kbps/ 96 kbps/ 128 kbps |
| Audio Transmission Mode |
Off / Line input / Audio output / Interactive (Half duplex) / Interactive (Full duplex) |
| Supported Protocol |
IPv6: TCP/IP, UDP/IP, HTTP, HTTPS, SSL/TLS, SMTP, DNS, NTP, SNMPv1/v2/v3, DHCPv6, RTP, MLD, ICMP, ARP, IEEE 802.1X, DiffServ, FTP, SFTP, LLDP, MQTT
IPv4: TCP/IP, UDP/IP, HTTP, HTTPS, SSL/TLS, RTSP, RTP, RTP/RTCP, SMTP, DHCP, DNS, DDNS, NTP, SNMPv1/v2/v3, UPnP, IGMP, ICMP, ARP, IEEE 802.1X, DiffServ, SRTP, FTP, SFTP, LLDP, MQTT, NTCIP |
| No. of Simultaneous Users |
Up to 14 users (Depends on network conditions) |
| Secure |
FIPS 140-2 level 3 (NXP® EdgeLock® SE050F),
Device Certificate GlobalSign® pre-installed, HTTPS,
User authentication, digest authentication, Host authentication,
IEEE802.1X, System log, Image transmission log, brute-force protection,
Alteration Detection |
| SDXC/SDHC/SD Memory Card (Option) |
- |
| Mobile Terminal Compatibility |
iPad / iPhone (iOS 8.0 or later), Android™ terminals |
| ONVIF®Profile |
M / S / T |
Input/Output
| COMPONENT |
SPECIFICATION |
| Audio Input *3 |
Pre-stripped wires |
| Audio Output *3 |
Output impedance: Approx. 600 Ω (unbalanced)
Output level: -20 dBV |
| External I/O Terminals *3 |
ALARM IN1
(Alarm input 1/ Black & white input/ Auto time adjustment input) (x1)
ALARM IN2 (Alarm input 2/ ALARM OUT) (x1)
ALARM IN3 (Alarm input 3/ AUX OUT) (x1)
Relay (x1) |
| Monitor Output |
- |
General
| COMPONENT |
SPECIFICATION |
| Safety |
UL (UL62368-1), c-UL (CSA C22.2 No.62368-1), CE, IEC62368-1 |
| EMC |
FCC (Part15 ClassA), ICES-003 ClassA, EN55032 ClassA, EN55035 |
| Power Source/Power Consumption |
[Power Source]
24V AC 50Hz/60Hz
24V DC
90W PoE++ (IEEE802.3bt Type4 Class 8 compliant)
60W PoE++ (IEEE802.3bt Type3 Class 6 compliant)
[Power Consumption]
Ambient operating temperatute -50 to 65℃ (White LED Light available):
24 V AC 50Hz/60Hz : 4.9 A / Approx. 78.7 W
24 V DC ：3.3 A / Approx. 79.2 W
90W PoE++ DC 54 V : 1.3 A / Approx. 70.2 W (Class 8 device)
Ambient operating temperatute -30 to 65℃ (White LED Light not available):
60W PoE++ DC 54 V : 930 mA / Approx. 50.2 W (Class 6 device) |
| Ambient Operating Temperature |
-50 °C to +65 °C {-58 °F to +149 °F} *
(Power On range: -30 °C to +65 °C {-22°F to +149°F})
(24V AC/DC, PoE++ Class 8)
-30 °C to +65 °C {-22 °F to +149°F} *
(Power On range: -20 °C to +65 °C {-4 °F to +149°F})
(PoE++ Class 6)
* If the White LED Light is constantly on, the upper limit of the operating temperature range is +50°C. |
| Ambient Operating Humidity |
10 % to 100 % (no condensation) |
| Water and Dust Resistance |
IP68/IP66 (IEC 60529), Type 4X (UL50E), Type 6P(UL50E), NEMA 4X compliant, NEMA 6P compliant |
| Shock Resistance |
IK10(IEC 62262) *
* Excluding front glass and LED cover |
| Wind Resistance |
Upright, Hanging:
Operable
Up to 75 m/s {approx. 167 mph}
Non-destructive
Up to 90 m/s {approx. 201 mph}
Leaning forward:
Operable
Up to 60 m/s {approx. 134 mph}
Non-destructive
Up to 90 m/s {approx. 201 mph} |
| Dimensions |
226 mm (W) x 450 mm (H) x 266 mm (D) {8-29/32 inches (W) x 17-23/32 inches (H) x 10-15/32 inches (D)}
(excluding the mounting and bump parts) |
| Mass (approx.) |
Approx. 8.1 kg {17.9 lbs}
(excluding attachments) |
| Finish |
Body: High-strength salt-resistant resin, die-cast, Gray (Munsell N7 semi-gloss)
Clear front cover: Clear glass |
| Easy Kitting |
Yes |
| Other |
Tamper-resistant enclosure*4
NEMA TS2 Compliant
Maximum temperature according to NEMA TS 2 (2.2.7): 74 °C (165 °F)
Heavy salt damage resistance specifications (ISO 14993 compliant) |
|
