Camera
| COMPONENT |
SPECIFICATION |
| Image Sensor |
Approx. 1/2.8 type CMOS image sensor |
| Scanning Area |
5.57 mm (H) × 3.13 mm (V)
{7/32 inches (H) × 1/8 inches (V)} |
| Minimum Illumination |
Color :
0.011 lx (30IRE, F1.6, 1/30s, AGC:11)*
0.015 lx (50IRE, F1.6, 1/30s, AGC:11)
0.001 lx (50IRE, F1.6, 16/30s, AGC:11)*
BW :
0.006 lx (50IRE, F1.6, 1/30s, AGC:11)
0.0004 lx (50IRE, F1.6, 16/30s, AGC:11)*
*Converted value |
| White Balance |
ATW1 / ATW2 / AWC |
| Shutter Speed |
[60fps mode] 1/60 Fix to 1/10000 Fix
[50fps mode] 1/50 Fix to 1/10000 Fix |
| Maximum shutter |
60 fps/30 fps/15 fps mode: Max.1/4000s to Max.16/30s
50 fps/25 fps/12.5 fps mode: Max.1/4000s to Max.16/25s |
| Intelligent Auto |
On / Off |
| Super Dynamic |
On / Off, The level can be set in the range of 0 to 31. |
| Dynamic Range |
Max.144 dB (Super Dynamic : On, Level 31) |
| Adaptive Black Stretch |
The level can be set in the range of 0 to 255. |
| Back Light Compensation/ High Light Compensation |
BLC (Back light compensation) / HLC (High light compensation) / Off
The level can be set in the range of 0 to 31 (only when Super dynamic / Intelligent Auto :Off) |
| Fog Compensation |
On / Off, The level can be set in the range of 0 to 8
(only when Intelligent auto / auto contrast adjust : Off) |
| Maximum Gain (AGC) |
The level can be set in the range of 0 to 11. |
| Color/BW (ICR) |
Off/On/Auto1(Normal)/Auto2(IR Light)/Auto3(SCC) |
| IR LED Light |
- |
| Digital Noise Reduction |
The level can be set in the range of 0 to 255. |
| Video Motion Detection (VMD) |
On / Off,
4 areas available |
| Scene Change Detection (SCD) |
On / Off,
1 areas available |
| Audio Detection |
On / Off |
| AI Sound Classification |
Gunshot, Yell, Vehicle horn, Glass break |
| AI Analytics |
AI Video Motion Detection, AI Face Detection,
AI People Detection, AI Vehicle Detection,
AI Non mask Detection (prior to V2.70), AI Occupancy Detection, AI Scene Change Detection
For details :
https://i-pro.com/products_and_solutions/en/surveillance/products/analytics-software
3rd party applications are also available.
https://i-pro.com/products_and_solutions/en/surveillance/solutions/edge-ai-platform/application-list |
| Privacy Zone |
On / Off,
Up to 32 zones available |
| VIQS |
On / Off,
Up to 8 zones available |
| Image Stabilizer |
On / Off
(Built-in gyro sensor) |
| Camera Title (OSD) |
On / Off,
Up to 40 characters (alphanumeric characters, marks) |
Lens
| COMPONENT |
SPECIFICATION |
| Optical zoom |
40x (Motorized zoom / Motorized Focus) |
| Extra zoom |
Max.60x (40x-60x when resolution is 1280x720) |
| Focal length |
4.25 - 170 mm {5/32 inches - 6-11/16 inches} |
| Angular Field of View |
[16 : 9 mode] Horizontal : 2.0° (TELE) – 65° (WIDE), Vertical : 1.2° (TELE) – 39° (WIDE)(TBD)
[ 4 : 3 mode] Horizontal : 1.5° (TELE) – 51° (WIDE), Vertical : 1.2° (TELE) – 39° (WIDE)(TBD) |
| Maximum Aperture Ratio |
1 : 1.6 (WIDE) – 1 : 4.95 (TELE) |
| Focus range |
3.0 m {118-1/8 inches} –∞ |
| Aperture range |
F1.6 - close |
DORI
| COMPONENT |
SPECIFICATION |
| Detect (25ppm / 8ppf) |
Wide: 60.3 m / 197.8 ft, Tele: 2199.9 m / 7217.6 ft |
| Observe (62.5ppm / 19ppf) |
Wide: 24.1 m / 79.1 ft , Tele: 880.0 m / 2887.1 ft |
| Recognize (125ppm / 38ppf) |
Wide: 12.1 m / 39.6 ft, Tele: 440.0 m / 1443.5 ft |
| Identify (250ppm / 76ppf) |
Wide: 6.0 m / 19.8 ft, Tele: 220.0 m / 721.8 ft |
System on Chip (SoC)
| COMPONENT |
SPECIFICATION |
| System on Chip (SoC) |
Ambarella CV25m |
Adjusting Angle
| COMPONENT |
SPECIFICATION |
| Adjusting Angle |
Horizontal : 360° Endless Panning, TILT : -20° to +90°, Yaw : 0° |
Pan /tilt
| COMPONENT |
SPECIFICATION |
| Panning Range |
360° Endless Panning |
| Panning Speed |
Manual: Approx. 0.065°/s – 150°/s, Preset: Up to approx. 700°/s |
| Tilting Range |
Operational -20° – +90° |
| Tilting Speed |
Manual: Approx. 0.065°/s –150°/s, Preset: Up to approx. 500°/s |
| Preset Positions |
256 positions |
| Auto Mode |
Auto track/ Auto pan/ Preset sequence/ Patrol |
| Self Return |
10 s/ 20 s/ 30 s/ 1 min/ 2 min/ 3 min/ 5 min/ 10 min/ 20 min/ 30 min/ 60 min |
| Active ClearSight |
Yes |
Browser GUI
| COMPONENT |
SPECIFICATION |
| GUI / Setup Menu Language |
English, Italian, French, German, Spanish, Portuguese, Russian, Chinese, Japanese |
| Browser *1 |
Microsoft Edge, Firefox, Google Chrome |
Network
| COMPONENT |
SPECIFICATION |
| Network IF |
10Base-T / 100Base-TX, RJ45 connector |
| Resolution H.265/ H.264/ JPEG (MJPEG) |
[16:9 mode (60fps mode)],[16:9 mode (30fps mode)],
[16:9 mode (50fps mode)],[16:9 mode (25fps mode)]
1920x1080, 1280x720, 640x360, 320x180
[4:3 mode (30 fps mode)], [4:3 mode (25 fps mode)]
1280x960, VGA, QVGA
[4:3 mode (15 fps mode)], [4:3 mode (12.5 fps mode)]
2048x1536* , 1280x960, VGA, QVGA
*Used bu super resolution techniques |
| H.265/H.264 Transmission Mode/Type *2 |
[Transmission Mode] Constant bit rate / VBR / Frame rate / Best effort
[Transmission Type] Unicast port (AUTO) / Unicast port (MANUAL) / Multicast |
| JPEG |
[Image Quality] 10 steps |
| Smart Coding |
GOP (Group of pictures) control:
Off/ Low (Variable GOP 1s-8s)/ Mid (Variable GOP 4s-16s)/
Advanced(Fixed GOP 60s w/1s key-frame)/
Frame rate control (Variable GOP 4s-16s with frame rate control)
*Advanced and Frame rate control are only available with H.265.
Smart VIQS: On(High)/On(Low)/Off, Smart P-picture control: On/Off |
| Audio compression method *3 |
G.726 (ADPCM) : 16 kbps / 32 kbps
G.711 : 64 kbps
AAC-LC*5 : 64 kbps / 96 kbps / 128 kbps |
| Audio Transmission Mode |
Off / Mic (Line) input / Audio output / Interactive (Half duplex) / Interactive (Full duplex) |
| Supported Protocol |
IPv6 : TCP/IP, UDP/IP, HTTP, HTTPS, SSL/TLS, SMTP, DNS, NTP, SNMPv1/v2/v3,
DHCPv6, RTP, MLD, ICMP, ARP, IEEE 802.1X, DiffServ
IPv4 : TCP/IP, UDP/IP, HTTP, HTTPS, SSL/TLS, RTSP, RTP, RTP/RTCP, SMTP,
DHCP, DNS, DDNS, NTP, SNMPv1/v2/v3, UPnP, IGMP, ICMP, ARP,
IEEE 802.1X, DiffServ, SRTP, MQTT, NTCIP |
| No. of Simultaneous Users |
Up to 14 users (Depends on network conditions) |
| Secure |
FIPS 140-2 level 3 (NXP® EdgeLock® SE050F), Device Certificate GlobalSign® pre-installed,
HTTPS, User authentication, Digest authentication, Host authentication,
IEEE802.1X, System log, Image transmission log, Brute-force protection, Alteration detection, Signed Firmware |
| SDXC/SDHC/SD Memory Card (Option) |
H.265 / H.264 recording :
Manual REC / Alarm REC (Pre/Post) / Schedule REC / Backup upon network failure
JPEG recording :
Manual REC / Alarm REC (Pre/Post) / Backup upon network failure
Compatible SDXC/SDHC/SD Memory Card :
microSDXC memory card : 64 GB, 128 GB, 256 GB, 512 GB
microSDHC memory card : 4 GB, 8 GB, 16 GB, 32 GB
microSD memory card : 2 GB |
| Mobile Terminal Compatibility |
iPad,
iPhone (iOS 8.0 or later),
Android™ terminals |
| ONVIF® Profile |
G / M / S / T |
Alarm
| COMPONENT |
SPECIFICATION |
| Alarm Source |
3 terminals input,
VMD alarm,
Command alarm,
Audio detection alarm |
| Alarm Actions |
SDXC/SDHC/SD memory recording, E-mail notification,
HTTP alarm notification Indication on browser, TCP alarm notification output |
Input/Output
| COMPONENT |
SPECIFICATION |
| Audio Input *4 |
ø3.5 mm stereo mini jack
Recommended applicable microphone: Plug-in power type
(Sensitivity of microphone:-51dB to -38dB (0 dB=1 V/Pa, 1 kHz))
Input impedance: Approx. 2 kΩ (unbalanced)
Supply voltage: 4.0V±0.5V
For line input : Input level : Approx. –10 dBV |
| Audio Output *4 |
ø3.5 mm stereo mini jack (monaural output)
Output impedance : Approx. 600Ω (unbalanced)
Output level : –20 dBV |
| External I/O Terminals *4 |
ALARM IN 1 (Alarm input 1/ Black & white input/ Auto time adjustment input) (x1)
ALARM IN 2 (Alarm input 2/ ALARM OUT) (x1), ALARM IN 3 (Alarm input 3/ AUX OUT) (x1) |
| Monitor Output |
- |
General
| COMPONENT |
SPECIFICATION |
| Safety |
UL (UL62368-1), c-UL (CSA C22.2 No.62368-1), CE, IEC62368-1 |
| EMC |
FCC (Part15 ClassA), ICES-003 Issue 7 ClassA, EN55032 ClassA, EN55035 |
| Other Standard |
NEMA-TS2 |
| Power Source and Power Consumption |
PoE++ (IEEE802.3bt), PoE++ DC54V: 700mA/Approx.37.8W (Class 6 device) |
| Ambient Operating Temperature |
-50 °C to +60 °C * (-58 °F to +140 °F)(PoE++)
(Power On range : –30 °C to +60 °C {–22 °F to +140 °F})(TBD)
Maximum temperature according to NEMA TS 2 (2.2.7) : 74℃(165℉)
* When using with the IR LED light constantly lit, the upper limit of the operating temperature range is +50°C {+122 °F}. |
| Ambient Operating Humidity |
10 to 100 % (no condensation) |
| Water and Dust Resistance |
IP66, IEC60529 measuring standard compatible, Type 4X(UL50E), NEMA 4X compliant |
| Shock Resistance |
IK10 (IEC 62262) |
| Wind Resistance |
Up to 40 m/s {approx. 89 mph} |
| Dimensions |
Maximum diameter:φ167mm × 205 mm (H){φ6-9/16 inches × 8-1/16 inches (H)}
Dome radius SR 77.5 mm {SR 3-1/16 inches}
(excluding an attachment for the conduit portion and protruding parts) |
| Mass (approx.) |
Approx. 3 kg (without attachment) |
| Finish |
Main body :
Aluminum die cast (Heavy-salt damage resistance coating), i-PRO white
Outer fixing screws : Stainless steel (Corrosion-resistant treatment)
Dome cover: Polycarbonate resin, Clear |
| Other |
Tamper-resistant enclosure *5 |
|
