| รายละเอียดสินค้า |
Camera
| COMPONENT |
SPECIFICATION |
| Image Sensor |
<Multi Part> 4x 1/2.7 type CMOS image sensor
<PTZ Part> 1/2.8 type CMOS image sensor |
| Scanning Area |
<Multi Part> 5.12 mm (H) × 3.84 mm (V)
{3/16 inches (H) × 5/32 inches (V)}
<PTZ Part> 5.57 mm (H) × 3.13 mm (V) {7/32 inches (H) × 1/8 inches (V)} |
| Minimum Illumination |
<Multi Part>
Color :
0.12 lx (30IRE, F2.0, 1/30 s, AGC:11)*
0.17 lx (50IRE, F2.0, 1/30 s, AGC:11)
0.011lx (50IRE, F2.0, 16/30 s, AGC:11)*
BW :
0.10 lx (50IRE, F2.0, 1/30 s, AGC:11)
0.007lx (50IRE, F2.0, 16/30 s, AGC:11)*
<PTZ Part>
Color :
0.011 lx (30IRE, F1.6, 1/30 s, AGC:11)*
0.015 lx (50IRE, F1.6, 1/30 s, AGC:11)
0.001x (50IRE, F1.6, 16/30 s, AGC:11)*
BW :
0.006 lx (50IRE, F1.6, 1/30 s, AGC:11)
0.0004lx (50IRE, F1.6, 16/30 s, AGC:11)*
*Converted Value |
| White Balance |
ATW1/ ATW2/ AWC |
| Maximum shutter |
<Multi Part>
15 fps mode: Max.1/10000s to Max.16/30s
<PTZ Part>
60 fps mode: Max.1/4000s to Max.16/30s
30 fps mode: Max.1/4000s to Max.16/30s
15 fps mode: Max.1/4000s to Max.16/30s |
| Intelligent Auto |
On / Off |
| Super Dynamic |
<Multi Part> On / Off, The level can be set in the range of 0 to 31.
<PTZ Part> On / Off, The level can be set in the range of 0 to 31.*1 |
| Dynamic Range |
<Multi Part> 108 dB max.(Super Dynamic: On, Level: 31)
<PTZ Part> 144 dB max.(Super Dynamic: On, Level: 31) |
| Adaptive Black Stretch |
The level can be set in the range of 0 to 255. |
| Back Light Compensation/High Light Compensation |
BLC (Back light compensation) / HLC (High light compensation) / Off (only when Super dynamic / Intelligent Auto : Off) |
| Fog Compensation |
On / Off (only when Intelligent auto / auto contrast adjust : Off) |
| Maximum Gain (AGC) |
The level can be set in the range of 0 to 11. |
| Color/BW (ICR) |
Off／On／Auto1(Normal)／Auto2(IR Light)／Auto3(SCC) |
| IR LED Light |
- |
| Digital Noise Reduction |
The level can be set in the range of 0 to 255. |
| Panorama |
- |
| Video Motion Detection (VMD) |
On / Off,
4 areas available |
| Scene Change Detection (SCD) |
On / Off,
1 areas available |
| Audio Detection |
On/Off |
| AI Sound Classification |
Selectable from Gunshot, Yell, Vehicle horn, Glass break |
| AI Analytics |
AI Video Motion Detection, AI Privacy Guard, AI Face Detection, AI People Detection, AI Vehicle Detection, AI Non mask Detection (prior to V2.70), AI Occupancy Detection, AI Scene Change Detection
For details :
https://i-pro.com/products_and_solutions/en/surveillance/products/analytics-software
3rd party applications are also available.
https://i-pro.com/products_and_solutions/en/surveillance/solutions/edge-ai-platform/application-list |
| Privacy Zone |
<Multi Part> On / Off, Up to 8 zones available
<PTZ Part> On / Off, Up to 32 zones available |
| VIQS |
<Multi Part> On / Off, Up to 8 zones available
<PTZ Part> On / Off, Up to 8 zones available |
| Image Stabilizer |
<Multi Part> -
<PTZ Part> On / Off (Built-in gyro sensor) |
| Image Rotation |
Upside-down: On/Off |
| Camera Title (OSD) |
On/ Off,
Up to 40 characters, Up to 2 Lines (alphanumeric characters, marks) |
| Focus Adjustment |
<Multi Part> -
<PTZ Part> Auto focus |
Lens
| COMPONENT |
SPECIFICATION |
| Optical zoom |
<Multi Part> 1x
<PTZ Part> 21x (Motorized zoom / Motorized focus) |
| Extra zoom |
<Multi Part> max 4.0x (when resolution is 640x360)
<PTZ Part> max 31x (when resolution is 1280x720) |
| Focal length |
<Multi Part> 3.2mm
<PTZ Part> 4.0mm - 84.6mm｛5/32inches - 3-11/32 inches｝ |
| Angular Field of View |
<Multi Part> Horizontal : 97 deg. / Vertical : 71 deg.
<PTZ Part> Horizontal : 3.7 ° to 77 ° / Vertical : 2.2 ° to 44° |
| Maximum Aperture Ratio |
<Multi Part> 2
<PTZ Part> 1：1.6（WIDE） to 1：4.5（TELE） |
| Focus range |
<Multi Part> 1 m {3.28 ft} to ∞
<PTZ Part> 1.5 m {59-1/16 inches} to ∞ |
DORI
| COMPONENT |
SPECIFICATION |
| Detect (25ppm / 8ppf) |
<Multi Part> 45.3 m / 148.6 ft
<PTZ Part> Wide: 48.3 m / 158.4 ft, Tele: 1188.9 m / 3900.5 ft |
| Observe (62.5ppm / 19ppf) |
<Multi Part> 18.1 m / 59.4 ft
<PTZ Part> Wide: 19.3 m / 63.4 ft, Tele:475.5 m / 1560.2 ft |
| Recognize (125ppm / 38ppf) |
<Multi Part> 9.1 m / 29.7 ft
<PTZ Part> Wide: 9.7 m / 31.7 ft, Tele: 237.8 m / 780.1 ft |
| Identify (250ppm / 76ppf) |
<Multi Part> 4.5 m / 14.9 ft
<PTZ Part> Wide: 4.8 m / 15.8 ft, Tele: 118.9 m / 390.0 ft |
System on Chip (SoC)
| COMPONENT |
SPECIFICATION |
| System on Chip (SoC) |
<Multi Part> Ambarella CV2
<PTZ Part> Ambarella CV25m |
Adjusting Angle
| COMPONENT |
SPECIFICATION |
| Adjusting Angle |
<Multi Part> Camera 1,2,3,4:Vertical: 40 ±7° (Adjust by vertical (TILT) angle)
<PTZ Part> Horizontal : 360° Endless Panning / Vertical : -15 to +195°/Yaw : 0° |
Pan /tilt
| COMPONENT |
SPECIFICATION |
| Panning Range |
360 °Endless panning |
| Panning Speed |
Manual ： 0.065 °/s – 150°/s, Preset ： Up to 500 °/s |
| Tilting Range |
Operational -15 – +195° |
| Tilting Speed |
Manual ： 0.065 °/s – 150°/s, Preset ： Up to 500 °/s |
| Preset Positions |
256 positions |
| Auto Mode |
Auto track / Auto pan/
Preset sequence/ Patrol |
| Self Return |
10 s/ 20 s/ 30 s/
1 min/ 2 min/ 3 min/ 5 min/ 10 min/ 20 min/ 30 min/ 60 min |
Browser GUI
| COMPONENT |
SPECIFICATION |
| Camera Control |
Brightness, AUX On / Off |
| Audio |
Mic (Line) Input : On / Off , Volume adjustment : Low / Middle / High
Audio Output : On / Off , Volume adjustment : Low / Middle / High |
| GUI / Setup Menu Language |
English, Italian, French, German, Spanish, Portuguese,
Russian, Chinese, Japanese |
| Browser |
Microsoft Edge, Firefox, Google Chrome |
Network
| COMPONENT |
SPECIFICATION |
| Network IF |
10 BASE-T/100 BASE-T/1000 BASE-T,
RJ45 connector *2 |
| Resolution H.265/ H.264/ JPEG (MJPEG) |
<Multi Part>
[4:3] (15fps mode)/[4:3] (12.5fps mode)
3072 x 2304*3, 2560x1920, 1280 x 960, VGA, QVGA
[4:3] (15fps Quad mode)/[4:3] (12.5fps Quad mode)
3072 x 2304*3, 2560x1920, 1280 x 960, VGA
[16:9] (15fps mode) / [16:9] (12.5fps mode)
3072 x 1728*3, 2560x1440, 1920 x 1080, 1280 x 720, 640×360, 320×180
[16:9] (15fps Quad mode)/[16:9] (12.5fps Quad mode)
3072 x 1728*3, 2560x1440, 1920 x 1080, 1280 x 720, 640×360
<PTZ Part>
[16:9 mode (60 fps mode)][16:9 mode (30 fps mode)][16:9 mode (50 fps mode)][16:9 mode (25 fps mode)]
1920x1080, 1280x720, 640x360, 320x180
[4:3 mode (30 fps mode)][4:3 mode (25 fps mode)]
1280x960, VGA, QVGA
[4:3 mode (15 fps mode)][4:3 mode (12.5 fps mode)]
2048x1536*3, 1280x960, VGA, QVGA |
| H.265/H.264 |
[Transmission Mode] Constant bit rate / VBR / Frame rate / Best effort
[Transmission Type] Unicast port (AUTO) / Unicast port (MANUAL) / Multicast |
| JPEG |
[Image Quality] 10 steps |
| Smart Coding |
GOP (Group of pictures) control : On (Frame rate control)* / On (Advanced)* / On (Mid) / On (Low) / Off
*On (Frame rate control) and On (Advanced) are only available with H.265.
Smart VIQS: On(High)/On(Low)/Off, Smart P-picture control: On/Off |
| Audio Compression |
G.726(ADPCM): 32 kbps/16 kbps, G.711: 64 kbps, AAC-LC: 64kbps/96kbps/128kbps *4 |
| Audio Transmission Mode |
Off / Mic (Line) input / Audio output / Interactive (Half duplex) / Interactive (Full duplex) |
| Supported Protocol |
<Multi Part>
IPv6: TCP／IP、UDP／IP、HTTP、HTTPS、SSL/TLS、SMTP、DNS、NTP、SNMPv1/v2/v3、DHCPv6、RTP、MLD、ICMP、ARP、IEEE 802.1X、DiffServ、MQTT
IPv4: TCP／IP、UDP／IP、HTTP、HTTPS、SSL/TLS、RTSP、RTP、RTP／RTCP、SMTP、DHCP、DNS、DDNS、NTP、SNMPv1/v2/v3、UPnP、IGMP、ICMP、ARP、IEEE 802.1X、DiffServ, SRTP、MQTT
<PTZ Part>
IPv6: TCP／IP、UDP／IP、HTTP、HTTPS、SSL/TLS、SMTP、DNS、NTP、SNMPv1/v2/v3、DHCPv6、RTP、MLD、ICMP、ARP、IEEE 802.1X、DiffServ
IPv4: TCP／IP、UDP／IP、HTTP、HTTPS、SSL/TLS、RTSP、RTP、RTP／RTCP、SMTP、DHCP、DNS、DDNS、NTP、SNMPv1/v2/v3、UPnP、IGMP、ICMP、ARP、IEEE 802.1X、DiffServ, SRTP, FTP, SFTP, MQTT, LLDP, NTCIP |
| No. of Simultaneous Users |
<Multi Part> 24 (Number of sessions that can connect to cameras at the same time)
* Depends on network conditions
<PTZ Part> 14 (Number of sessions that can connect to cameras at the same time)
* Depends on network conditions |
| Secure |
FIPS 140-2 level 3 (NXP® EdgeLock® SE050F), Device Certificate GlobalSign® pre-installed,
HTTPS, User authentication, Digest authentication, Host authentication,
IEEE802.1X, System log, Image transmission log, Brute-force protection, Alteration detection, Signed Firmware |
| SDXC/SDHC/SD Memory Card |
microSDXC memory card：64 GB, 128 GB, 256 GB, 512 GB
microSDHC memory card：4 GB, 8 GB, 16 GB, 32 GB , microSD memory card ：2 GB |
| Mobile Terminal Compatibility |
iPad / iPhone (iOS 8.0 or later),
AndroidTM terminals |
| ONVIF® Profile |
G / M / S / T |
Alarm
| COMPONENT |
SPECIFICATION |
| Alarm Source |
3 terminals input, VMD alarm, SCD alarm, Command alarm, Audio detection alarm |
| Alarm Actions |
SDXC/SDHC/SD memory recording, E-mail notification, HTTP alarm notification Indication on browser, TCP alarm notification output |
Input/Output
| COMPONENT |
SPECIFICATION |
| Audio input *6 |
ø3.5 mm stereo mini jack
For microphone input :
Recommended applicable microphone : Plug-in power type (Sensitivity of microphone : -51 dB～-38dB (0 dB=1 V/Pa, 1 kHz))
Input impedance : Approx. 2 kΩ (unbalanced)
Supply voltage：2.5 V ±0.5 V
For line input：Input level: Approx. –10 dBV |
| Audio Output *6 |
ø3.5 mm stereo mini jack (Audio output is monaural.)
Output impedance: Approx. 600 Ω (unbalanced) , Output level: –20 dBV |
| External I/O Terminals *6 |
ALARM IN 1 (Alarm input 1/ Black & white input/ Auto time adjustment input) (x1)
ALARM IN 2 (Alarm input 2/ ALARM OUT) (x1) , ALARM IN 3 (Alarm input 3/ AUX OUT) (x1) |
| Monitor Output |
Yes (for adjustment)
Φ3.5mm stereo mini jack, NTSC or PAL signal can be output from camera
*WV-QCA501A is required |
General
| COMPONENT |
SPECIFICATION |
| Safety |
UL (UL62368-1), c-UL (CSA C22.2 No.62368-1), CE, IEC62368-1 |
| EMC |
FCC (Part15 ClassA), ICES-003 ClassA, EN55032 ClassA, EN55035 |
| Power Source and Power Consumption |
PoE++（IEEE802.3bt compliant):
DC 54 V : 0.66A/Approx. 35.6 W (Class 5 device) |
| Ambient Operating Temperature |
–40 °C to +55 °C {–40 °F to 131 °F}
(Power On range: –20 °C to +55 °C {–4 °F to 131°F})
Maximum temperature according to NEMA TS 2 (2.2.7) : 74℃(165℉) |
| Ambient Operating Humidity |
10 % to 100 % (no condensation) |
| Anti-Condensation System |
Temish element |
| Water and Dust Resistance |
IP67/IP66 (IEC 60529),
Type 4X (UL50E),
NEMA 4X compliant |
| Shock Resistance |
IK10 (IEC 62262) |
| Wind Resistance |
Up to 40 m/s {approx. 89 mph} |
| Other standard support |
NEMA TS 2 (2.2.7-2.2.9) |
| Dimensions |
ø250 mm x 195 mm (H) |
| Mass (approx.) |
Approx. 3.8 kg |
| Finish |
Main body: Aluminum die cast, i-PRO white
Outer fixing screws: Stainless steel (Corrosion-resistant treatment)
Dome cover: PC resin, Clear |
|
