| รายละเอียดสินค้า |
Camera
| COMPONENT |
SPECIFICATION |
| Image Sensor |
Approx. 1/2.8 type CMOS image sensor |
| Minimum Illumination |
Color : 0.015 lx, BW : 0.006 lx (F1.6, Maximum shutter : Off (1/30s), AGC : 11)
BW : 0 lx (F1.6, Maximum shutter : Off (1/30 s), AGC : 11, when the IR LED is lit)
Color : 0.001 lx, BW : 0.0004 lx (F1.6, Maximum shutter : max. 16/30s, AGC : 11) |
| Intelligent Auto |
On / Off |
| Shutter Speed |
1/30 Fix to 1/10000 Fix
*1/30 Fix to 2/120 Fix is available during 30 fps mode only.
*1/60 Fix is available during 60 fps mode only. |
| Super Dynamic |
On / Off, the level can be set in the range of 0 to 31. |
| Dynamic Range |
144 dB (Super Dynamic : On) |
| Image Settings |
Gain (AGC), White balance |
| Image Compensation |
Adaptive black stretch, Back light compensation (BLC), Fog compensation,
High light compensation (HLC), Digital noise reduction |
| Color/BW (ICR) |
Off / On (IR Light Off) / On (IR Light On) / Auto1 (IR Light Off) / Auto2 (IR Light On) |
| IR LED Light |
High / Middle / Low / Off Maximum irradiation distance
350 m {approx. 1150 ft}(AC 24 V/ Tested PoE injector)
150 m {approx. 500 ft}(PoE+ device) |
| Video Motion Detection (VMD) |
On / Off,
4 areas available |
| Intelligent VMD (i-VMD) |
Type4 Bundled License |
| Stabilizer |
On / Off (available only in the 30 fps mode) |
| Privacy Zone |
Filling / Pixelate / Off (up to 32 zones available) |
| Camera Title (OSD) |
On / Off
Up to 20 characters (alphanumeric characters, marks) |
Lens
| COMPONENT |
SPECIFICATION |
| Zoom Ratio |
40 x Optical zoom (Motorized zoom / Motorized focus) |
| Digital (Electronic) Zoom |
16 x |
| Focal Length |
4.25 mm – 170 mm {5/32 inches – 6-11/16 inches} |
| Maximum Aperture Ratio |
1 : 1.6 (WIDE) – 1 : 4.95 (TELE) |
| Focus Range |
3.0 m {9 ft 10-1/8 inches} – ∞ |
| Angular Field of View |
[16 : 9 mode]
Horizontal : 1.9 ° (TELE) – 66 ° (WIDE)
Vertical : 1.1 ° (TELE) – 39 ° (WIDE)
[4 : 3 mode]
Horizontal : 1.4 ° (TELE) – 51 ° (WIDE)
Vertical : 1.1 ° (TELE) – 39 ° (WIDE) |
Pan/tilt
| COMPONENT |
SPECIFICATION |
| Panning Range |
360° Endless panning |
| Panning Speed |
Manual : Approx. 0.065°/s – 150°/s
Preset : Up to approx. 300°/s |
| Tilting Range |
Operational range : –30° – +210°
Recommended range : 0° – 180° |
| Tilting Speed |
Manual : Approx. 0.065°/s – 150°/s
Preset : Up to approx. 300°/s |
| Preset Positions |
256 positions |
| Auto Mode |
Auto track / Auto pan / Preset sequence / Patrol |
| Self Return |
10 s/ 20 s/ 30 s/ 1 min/ 2 min/ 3 min/ 5 min/
10 min/ 20 min/ 30 min/ 60 min |
Browser GUI
| COMPONENT |
SPECIFICATION |
| Camera Control |
Pan/Tilt, Zoom, Focus, Auto mode, Brightness,
Preset, AUX, Rec. on SD, Log, Viewer software |
| Audio |
Mic (Line) Input : On / Off Volume adjustment : Low / Middle / High
Audio Output : On / Off Volume adjustment : Low / Middle / High |
| GUI / Setup Menu Language |
English, Italian, French, German, Spanish,
Portuguese, Russian, Chinese, Japanese |
Network
| COMPONENT |
SPECIFICATION |
| Network IF |
10Base-T / 100Base-TX, RJ45 connector |
| Resolution H.265/ H.264 JPEG (MJPEG) |
[16 : 9]
1920×1080 / 1280×720 / 640×360 / 320×180
[ 4 : 3]
2048×1536* / 1280×960 / 800×600 / VGA / 400×300 / QVGA
* Used by super resolution techniques |
| H.265/H.264 |
[Transmission Mode]
Constant bit rate / VBR / Frame rate / Best effort
[Transmission Type]
Unicast / Multicast |
| JPEG |
[Image Quality]
10 steps |
| Smart Coding |
[Smart Facial Coding]*
On(Smart Facial Coding)/ On(AUTO VIQS)/ Off
*Smart Facial Coding is only available with Stream(1).
[GOP(Group of pictures) control]
On(Frame rate control)*/ On(Advanced)*/ On(Mid.)/ On(Low)/ Off
*On(Frame rate control) and On(Advanced) are only available with H.265. |
| Audio Compression |
G.726 (ADPCM) : 16 kbps / 32 kbps,
G.711 : 64 kbps,
AAC-LC : 64 kbps / 96 kbps / 128 kbps |
| Audio Transmission Mode |
Off / Mic (Line) input / Audio output / Interactive (Half duplex) / Interactive (Full duplex) |
| Supported Protocol |
IPv6: TCP/IP, UDP/IP, HTTP, HTTPS, RTP, FTP, SMTP, DNS, NTP, SNMP, DHCPv6, MLD, ICMP, ARP, IEEE 802.1X, DiffServ
IPv4: TCP/IP, UDP/IP, HTTP, HTTPS, RTSP, RTP, RTP/RTCP, FTP, SMTP, DHCP, DNS, DDNS, NTP, SNMP, UPnP, IGMP, ICMP, ARP, IEEE 802.1X, DiffServ |
| Maximum concurrent access number |
14 (Number of sessions that can connect to cameras at the same time)
*Depends on network conditions |
| SDXC/SDHC/SD Memory Card (Option) |
H.265 / H.264 recording: Manual REC / Alarm REC (Pre/Post) / Schedule REC / Backup upon network failure
JPEG recording: Manual REC / Alarm REC (Pre/Post) / Backup upon network failure
Compatible SDXC/SDHC/SD Memory Card: Panasonic 2 GB, 4 GB*, 8 GB*, 16 GB*, 32 GB*, 64 GB**, 128 GB**, 256 GB** model
*SDHC card, ** SDXC card (except miniSD card and microSD card) |
| Mobile Terminal Compatibility |
iPad / iPhone,
Android TM mobile terminals |
| ONVIF® Profile |
G / S / T |
Alarm
| COMPONENT |
SPECIFICATION |
| Alarm Source |
3 terminals input, VMD alarm, Command alarm,
Audio detection alarm, Auto track alarm |
| Alarm Actions |
SDXC/SDHC/SD memory recording, E-mail notification, HTTP alarm notification, Indication on browser, FTP image transfer, Panasonic protocol output |
Input/Output
| COMPONENT |
SPECIFICATION |
| Audio Input |
ø3.5 mm stereo mini jack (Audio input is monaural.)
Input impedance: Approx. 2 kΩ (unbalanced)
(Applicable microphone : Plug-in power type)
Supply voltage : 4.0 V ±0.5 V |
| Audio Output |
ø3.5 mm stereo mini jack (Audio output is monaural.)
Output impedance : Approx. 600 Ω (unbalanced) |
| External I/O Terminals |
ALARM IN1(Alarm input 1/ Black & white input/ Auto time adjustment input), ALARM IN2(Alarm input 2/ ALARM OUT), ALARM IN3 (Alarm input 3/ AUX OUT) (x1 for each) |
| Monitor Output |
Yes (for adjustment)
Φ3.5mm stereo mini jack, NTSC or PAL signal can be output from camera |
General
| COMPONENT |
SPECIFICATION |
| Safety |
UL (UL60950-1), c-UL (CSA C22.2 No.60950-1), CE, IEC60950-1 |
| EMC |
FCC (Part15 ClassA), ICES003 ClassA, EN55032 ClassA, EN55035 |
| Power Source and Power Consumption |
AC24 V 3.4 A, Approx. 55 W
PoE+ (IEEE802.3at compliant): DC 54V 470 mA, Approx. 25 W(Class4 device)
Tested POE Injector (60 W) : DC 54V 1.0 A, Approx. 50 W |
| Ambient Operating Temperature |
–50 °C to +60 °C {–58 °F to +140 °F}
(AC 24 V/ Tested PoE injector (60 W))*
–30 °C to +60 °C {–22 °F to +140 °F} (PoE+ device)*
{Power On range: –30 °C to +60 °C (–22 °F to +140 °F)}
* When using with the IR LED light constantly lit, the upper limit of the operating temperature range is +45°C {+113 °F}. |
| Ambient Operating Humidity |
10 to 100 % (no condensation) |
| Water and Dust Resistance |
IP66 (IEC60529), Type 4X (UL50E), NEMA 4X compliant |
| Shock Resistance |
IK10 (IEC62262) |
| Wind Resistance |
up to 40 m/s {approx. 89 mph} |
| Dimensions |
Maximum ø249 mm × 465 mm (H){ø9-13/16 inches × 18-5/16 inches (H)} |
| Mass (Approx.) |
Approx. 8.2 kg {18.10 lbs}
(including attachment pipe : Approx. 200 g {0.44 lbs} and cable cover.) |
| Finish |
Main body : Aluminum die cast, Fine silver
Outer fixing screws : Stainless steel (Corrosion-resistant treatment)
Front Panel : Polycarbonate resin
(with ClearSight coating (rain wash coating)), Clear |
|
