| รายละเอียดสินค้า |
Camera
| COMPONENT |
SPECIFICATION |
| Image Sensor |
1/3 type MOS image sensor |
| Scanning Mode |
Progressive |
| Scanning Area |
5.28 mm (H) x 3.30 mm (V) {7/32 inches (H) x 1/8 inches (V)} |
| Minimum Illumination |
Color: 0.1 lx (F2.2, Maximum shutter : Off (1/30s), AGC : High)
0.007 lx (F2.2, Maximum shutter : Max. 16/30s, AGC : High)
BW: 0.06 lx (F2.2, Maximum shutter : Off (1/30s), AGC : High)
0.004 lx (F2.2, Maximum shutter : Max. 16/30s, AGC : High) |
| White Balance |
AWC (2,000 ~ 10,000 K),
ATW1 (2,700 ~ 6,000 K),
ATW2 (2,000 ~ 6,000 K) |
| Light Control Mode |
ELC / Indoor scene 50 Hz / Indoor scene 60 Hz |
| Wide Dynamic Range |
On / Off |
| Adaptive Black Stretch |
On / Off (only when Wide dynamic range : Off) |
| Fog Compensation |
On / Off (only when Wide dynamic range : Off) |
| High Light Compensation (HLC) |
On / Off (only when Wide dynamic range / Back light compensation (BLC): Off) |
| AGC |
On (High) / On (Mid) / On (Low) / Off |
| Maximum Shutter |
max. 1/10,000 s, max. 1/4,000 s, max. 1/2,000 s, max. 1/1,000 s,
max. 1/500 s, max. 1/250 s, max. 1/120 s, max. 1/100 s,
max. 2/120 s, max. 2/100 s, max. 3/120 s, max. 3/100 s,
max. 1/30 s, max. 2/30 s, max. 4/30 s, max. 6/30 s,
max. 10/30 s, max. 16/30 s |
| Day/Night (Electrical) |
Off / Auto |
| Digital Noise Reduction |
High / Low |
| Video Motion Detection |
On / Off, 4 areas available |
| Privacy Zone |
On / Off (up to 8 zones available) |
| VIQS |
On / Off (Max. 8 locations) |
| Camera Title (OSD) |
Up to 20 characters (alphanumeric characters, marks), On / Off |
| Focus Adjustment |
MANUAL |
Lens
| COMPONENT |
SPECIFICATION |
| Focal Length |
1.95 mm {1/16 inches} |
| Digital (electronic) zoom |
Choose from 3 levels of x1, x2, x4 |
| Zoom ratio |
x1
WV-SBV131M : Extra zoom x3 (16 : 9 mode) / x2.5 (4 : 3 mode)
WV-SBV111M : Extra zoom x2 |
| Angular Field of View |
[16 : 9 mode] Horizontal : 109 ° Vertical : 73 °
[4 : 3 mode] Horizontal : 97 ° Vertical : 79 ° |
| F Number |
F2.2 |
| Focus Distance |
0.5 m - ∞ |
Adjusting Angle
| COMPONENT |
SPECIFICATION |
| Adjusting Angle |
Horizontal : ±170 °, Vertical : ±90 °
Image tilt adjustment range : -170 ° (Left) to +170 ° (Right) |
Browser GUI
| COMPONENT |
SPECIFICATION |
| Camera Control |
Brightness |
| Display Mode |
Spot, Quad: Image from 16 cameras can be displayed in
4 different Quad screens or 16 split screen (JPEG only).
20 characters camera title available. |
| Camera Title |
Up to 20 alphanumeric characters |
| Clock Display |
Time : 12H/24H
Date : 5 formats on the browser
Summer time (Manual) |
| One Shot Capture |
A still picture will be displayed on a newly opened window. |
| SD Memory Data Download |
Still or motion Images recorded in the SDXC/SDHC/SD memory card can be downloaded. |
| GUI/Setup Menu Language |
English, Italian, French, German, Spanish, Portuguese, Russian, Chinese, Japanese |
| System Log |
Up to 100 (Internal), Up to 4,000 (SDXC/SDHC/SD memory
when the recording format is set to JPEG.) error logs |
| Supported OS |
Microsoft® Windows® 10, Microsoft® Windows® 8.1,
Microsoft® Windows® 8, Microsoft® Windows® 7 |
| Supported Browser |
Windows® Internet Explorer® 11 (32 bit)
Windows® Internet Explorer® 10 (32 bit)
Windows® Internet Explorer® 9 (32 bit)
Windows® Internet Explorer® 8 (32 bit) |
Network
| COMPONENT |
SPECIFICATION |
| Network IF |
10Base-T / 100Base-TX, M12 connector (female) |
| Image Resolution |
•2 mega pixel [16 : 9]
H.264 (1)(2) / JPEG (1)(2)(3)
1,920 x 1,080 / 1,280 x 720 / 640 x 360 / 320 x 180 / 160 x 90
H.264 (3)(4)
1,280 x 720 / 640 x 360 / 320 x 180 / 160 x 90
•2 mega pixel [4 : 3]
H.264 (1)(2) / JPEG (1)(2)(3)
1,600 x 1,200 / 1,280 x 960 / 800 x 600 / VGA / 400 x 300 /
QVGA / 160 x 120
H.264 (3)(4)
1,280 x 960 / 800 x 600 / VGA / 400 x 300 / QVGA / 160 x 120
•3 mega pixel [4 : 3] * Used by super resolution techniques
H.264 (1)(2) / JPEG (1)(2)(3)
2,048 x 1,536 / 1,280 x 960 / 800 x 600 / VGA / 400 x 300 /
QVGA / 160 x 120
H.264 (3)(4)
1,280 x 960 / 800 x 600 / VGA / 400 x 300 / QVGA / 160 x 120 |
| H.264 MPEG-4 |
[Transmission Mode]
Constant bit rate / Variable bit rate / Framerate priority / Best effort / Advanced VBR
[Frame Rate]
1 / 3 / 5 / 7.5 / 10 / 12 / 15 / 20 / 30 fps
[Bit Rate/Client]
64 / 128 / 256 / 384 / 512 / 768 / 1,024 / 1,536 / 2,048 / 3,072 /
4,096 / 6144* / 8,192* / 10,240* / 12,288* / 14,336* / 16,384* / 20,480* / 24,576* / 30,720* / 40,960 kbps*
* The available range of the H.264 bit rate varies depending on the setting selected for “image capture size”.
[Image Quality]
<When Constant bit rate or Best effort is selected>
Low / Normal / Fine
<When Variable bit rate is selected>
0 SUPER FINE /1 FINE /2 / 3 / 4 / 5 NORMAL / 6 / 7 / 8 / 9LOW
[Smart Coding mode]
On (Low / Mid / High) / Off (Only when "Variable bit rate" is selected)
[Transmission Type]
UNICAST / MULTICAST |
| JPEG |
[Image Quality]
10 steps
[Refresh interval]
0.1 fps - 30 fps
[Transmission Type]
PULL / PUSH |
| Total Bit Rate |
64 / 128 / 256 / 384 / 512 / 768 / 1,024 / 2,048 / 4,096 / 8,192 kbps / Unlimited |
| Supported Protocol |
IPv6: TCP/IP, UDP/IP, HTTP, HTTPS, RTP, FTP, SMTP, DNS, NTP,
SNMP, DHCPv6, MLD, ICMP, ARP
IPv4: TCP/IP, UDP/IP, HTTP, HTTPS, RTSP, RTP, RTP/RTCP, FTP,
SMTP, DHCP, DNS, DDNS, NTP, SNMP, UPnP, IGMP, ICMP,ARP |
| FTP Client |
Alarm image transmission, FTP periodic transmission
(When the FTP transmission is failed, backup on an optional
SDXC/SDHC/SD memory card is available.) |
| No. of Simultaneous Users |
Up to 14 users (Depends on network conditions) |
| SDXC/SDHC/SD Memory Card (Option) |
Manufactured by Panasonic (except miniSD card and microSD card)
SDXC memory card : 64 GB, 128 GB
SDHC memory card : 4 GB, 8 GB, 16 GB, 32 GB
SD memory card : 256 MB, 512 MB, 1 GB, 2 GB |
| Cellular Phone Compatibility |
JPEG image |
| Mobile Terminal Compatibility |
iPad, iPhone, iPod touch(iOS 4.2.1 or later) ,
AndroidTM mobile terminals |
Alarm
| COMPONENT |
SPECIFICATION |
| Alarm Source |
VMD, Command alarm |
| Alarm Actions |
SDXC/SDHC/SD memory recording, E-mail noti cation,
Indication on browser, FTP image transfer, TCP alarm noti cation output |
| Alarm Log |
With SDXC/SDHC/SD memory card: 5,000 logs, without SDXC/SDHC/SD memory card: 1,000 logs |
| Schedule |
VMD |
Input/Output
| COMPONENT |
SPECIFICATION |
| Monitor Output |
- |
General
| COMPONENT |
SPECIFICATION |
| Safety/EMC Standard |
<Safety> UL (UL60950-1), C-UL (CAN/CSA C22.2 No.60950-1), CE, IEC60950-1
<EMC> FCC Part15 ClassA, ICES003 ClassA, EN55022 ClassB, EN55035 |
| Power Source and Power Consumption |
PoE (IEEE802.3af compliant) / PoE (Alternative A) : 48 V DC : 80 mA / Approx.3.8 W (Class 2 device) |
| Ambient Operating Temperature |
-40 °C to +60 °C {-40 °F to 140 °F}
(Power On range : -30 °C to +60 °C {-22 °F to 140 °F}) |
| Ambient Operating Humidity |
10 % to 90 % (no condensation) |
| Impact Protection |
Compliant with IK10 (IEC 62262) |
| Water and Dust Resistance |
IP66 (IEC60529), IP6K9K, Type 4X (UL50), NEMA 4X compliant |
| Railway Application |
EN50155-T3, EN50121, ECE-R10, EN45545, EN50498 |
| Dimensions |
100 mm {3-15/16 inches} (W), 80 mm {3-5/32 inches} (H), 161 mm {6-11/32 inches} (D) |
| Mass (Approx.) |
Approx. 750 g {1.65 lbs} |
| Finish |
Main body : Aluminum die cast, Light gray
Dome cover : Polycarbonate resin, Clear (with hard coating) |
| Others |
Tamper-resistant dome cover |
|
