| รายละเอียดสินค้า |
Supported Camera
| COMPONENT |
SPECIFICATION |
| Compatible Vendor |
i-PRO series Network cameras,
ONVIF NVT conformant camera and encoder |
| Supported Image Format |
H.265(HEVC), H.264, JPEG |
| Supported Image Resolution (Depending on the camera) |
•Aspect ratio [4 : 3]
3072x2304, 2560x1920, 2048x1536, 1600x1200, 1280x960, 800x600, 640x480
•Aspect ratio [16 : 9]
3840x2160, 3328x1872, 3072x1728, 2688x1520, 2560x1440, 1920x1080, 1280x720, 640x360
•Aspect ratio [1 : 1]
2992x2992, 2816x2816, 2192x2192, 2048x2048, 1440x1440, 1280x1280, 1200x1200
•Aspect ratio [9 : 16]
2160x3840, 1872x3328, 1728x3072, 1520x2688, 1440x2560, 1080x1920, 720x1280, 360x640 |
| Supported Audio Format |
AAC-LC, G.711 for ONVIF |
| Maximum Number of Cameras |
MAX. 4 |
Recording
| COMPONENT |
SPECIFICATION |
| Recording Mode |
Event, Schedule, Emergency, Pre-event |
| Pre-alarm Recording |
Up to 15 seconds *When the delivery speed from the network camera is less than 4 Mbps. |
| Sub-stream Recording |
- |
| Scheduled Recording Mode |
4 programs, 6 time zones/day, Independent setup for each day of the week |
| Frame Rate/Camera |
Up to 60 fps (Depending on the camera) |
Main Unit Functions
| COMPONENT |
SPECIFICATION |
| Camera Control |
Pan/Tilt, Zoom, Focus, Brightness, Preset position call and program (up to 256), Auto mode, Click centering, Wheel zoom, Zoom reset, Auto Back Focus, Aux, Wiper (for WV-SUD638) |
| Multiscreen Mode |
[Main monitor]
• Control screen 4 split screen display
• Wide view screen 2 / 3 / 4 split screen display,1 screen sequence
[Sub monitor]
1 screen sequence, 4 split screen display |
| Playback Control |
PLAY, Rev PLAY, Pause, Stop, FF, FR, Prev Record, Next Record, Prev Image, Next Image, Go to Date, Go to Last (30 s), Time-saving playback |
| Search Mode |
Search criteria : Time date, Playback by designating a timeline, VMD, Thumbnail |
| Copy |
File Format: Original Format / MP4
Recorded data of selected cameras and time date range can be copied to USB storage. |
| Camera Title |
Up to 16 Characters |
| Clock Display |
Time : 12H/24H,
Date : 5 formats |
| Digital Zoom |
Live / Play: 1.25x 1.5x 1.75x, 2x, 2.5x, 3x, 3.5x 4x, 5x, 6x, 7x, 8x (only for 1-screen or 4-screen) |
| System Log |
Operator access (500), Network error (100), Error (1,000), Event (1000), Operation (500) |
| System Setup |
Setup page in English, French, Italian, Spanish, German, Portuguese, Thai, Vietnamese, Simplified Chinese, Traditional Chinese, Japanese |
| 360 Camera Dewarp |
Only 1ch display mode. |
| re-encoding |
2Client |
| SD Memory Data Download |
Images recorded in the SD card in the i-PRO series cameras can be transferred to the recorder automatically.
(H.265/H.264) |
Browser GUI
| COMPONENT |
SPECIFICATION |
| Camera Control |
Pan/Tilt, Zoom, Focus, Brightness, Preset position call and program (up to 256), Auto mode, Zoom reset, Aux, Wiper (for WV-SUD638) |
| Playback Control |
PLAY, Rev PLAY, Pause, Stop, FF, FR, Prev Record, Next Record, Prev Image, Next Image, Go to Date, Go to Last (30 s) |
| Search Mode |
Search criteria : Time date, Event type, Camera number |
| Display Mode |
1 screen |
| Image Download |
File Format: Original Format
Recorded data of selected camera and time range can be downloaded to a PC.
Viewer software can be downloaded separately. |
| Copy |
File Format: Original Format / MP4
Recorded data of selected cameras and time date range can be copied to USB storage. |
| Camera Title |
Up to 16 characters |
| Clock Display |
On the browser. Time: 12H/24H, Date: 5 formats |
| Alarm Control |
Reset |
| Digital Zoom |
- |
| System Log |
Operator access (500), Network error (100), Error (1,000), Event (1000), Operation (500) |
| GUI Language |
English, French, Italian, Spanish, German, Portuguese, Thai, Vietnamese, Simplified Chinese, Traditional Chinese, Japanese |
| Required PC |
CPU: Intel® Core™ i7-860 or faster , RAM : 4 GB or more,
VRAM: 128 MB or more (Min. 64 MB), Microsoft® DirectX® 9.0c or later |
| Web Browser |
Microsoft Edge*, Google Chrome, Mozilla Firefox
*Not compatible with Internet Explorer mode |
Alarm/Event
| COMPONENT |
SPECIFICATION |
| Alarm Source |
4x Terminal inputs, 4x Camera alarms (TCP alarm notification), 128x Command alarms |
| Event Mode |
Off / On |
| Alarm Action |
Alarm recording, E-mail notification, Alarm message, Camera positioning, Terminal output, TCP/HTTP alarm notification output, Buzzer, Indicator |
| Alarm Control |
Reset |
| Event log |
1000 |
Input/Output
| COMPONENT |
SPECIFICATION |
| Monitor (HDMI) Connector |
[Main monitor] HDMI 4K UHD(3840x2160p)/30Hz, 4K UHD(3840x2160p)/25Hz, 1920x1080p /60Hz, 1920x1080p /50Hz
[Sub monitor] HDMI 1920x1080p /60Hz, 1920x1080p /50Hz |
| Alarm/Control Terminal |
[Alarm] Alarm input 4, Alarm output 1
[Control] +5 V output, Emergency recording input, General purpose input/output
[Error / Warning] HDD error / Recording error output, Camera error output |
| Mouse Connection Port |
1 (USB 2.0) |
| Network Port (PC) |
1x 10BASE-T / 100BASE-TX / 1000BASE-T (RJ45) |
| Network Port (Camera) |
4x 10BASE-T / 100BASE-TX(RJ45), (RJ45, PoE+),
PoE Budget (4 port Total : Max 50 W, Each port Max : 30 W) |
| USB Storage |
USB 3.0 / USB 2.0 memory,
USB 3.0 / USB 2.0 connected HDD (except bus powered device) |
Network
| COMPONENT |
SPECIFICATION |
| Network Interface |
10BASE-T / 100BASE-TX / 1000BASE-T (RJ45) |
| Maximum Recording Rate |
48 Mbps |
| Maximum Bandwidth |
Total 96 Mbps |
| Supported Protocol |
IPv4: TCP/IP, UDP/IP, HTTP, HTTPS, SMTP, DNS, NTP, SNMP, RTP, RTSP, ICMP, ARP
IPv6: ICMPv6 |
| E-mail |
Upon Alarm or Warning |
| No. of Simultaneous Users |
16 or less |
| User Registration |
Up to 32 users |
| User Level |
3 Levels
(Programmable) |
| Partitioning |
User level - Camera
(View & Control, No Access) |
| Security Method |
User authentication (ID and Password), Host authentication, Alteration detection, SSL/TLS |
Other Functions
| COMPONENT |
SPECIFICATION |
| Time Synchronization |
NTP
(Server/Client) |
| Summer Time |
User definable
(using menu setup) |
| Remote Monitoring (Cloud service for P2P) |
1000 cameras or less
Allows the PC and mobile APP full access the multiple NU series / NX series NVRs. |
HDD
| COMPONENT |
SPECIFICATION |
| Type |
3.5 inch |
| Maximum Capacity |
20 TB |
| RAID |
- |
Viewer Software
| COMPONENT |
SPECIFICATION |
| Playback Control |
PLAY, Rev PLAY, Pause, FF, FR, Prev Record, Next Record, Prev Image, Next Image |
| Additional Functions |
[NX Viewer]
Alteration detection, Save as JPEG, Two times zoom, Print, Copy, Aspect ratio switching, fish eye correction, corridor display |
| Supported OS, Language |
Language of the software will be English or Japanese |
General Specifications
| COMPONENT |
SPECIFICATION |
| Safety / EMC Standard |
CE/UKCA
(EN55032/EN55035) |
| Power Source |
DC 54 V 1.67 A
(included AC power adapter) |
| Power Consumption |
90 W
(DC 54 V 1.67 A) |
| Ambient Operating Temperature |
Main body :
0 °C to +45 °C (32 °F to 113 °F)
Mouse (provided) :
+5 °C to +40 °C (41 °F to 104 °F)
AC power adapter (provided) :
0℃to+40℃ (32°F to 104°F) |
| Ambient Operating Humidity |
5 % to 90 %
(without condensation) |
| Maximum Operating Altitude |
2,000 m (6,562 feet) above sea level |
| Dimensions |
340 mm(W) x 44 mm(H) x 230 mm(D)
{13-3/8 inches (W) x 1-23/32 inches (H) x 9-1/16 inches (D)} |
| Mass (approx.) |
App 2.1 kg {4.6 lbs} |
|
